MIDI

ODD Ball is a Bluetooth MIDI device and can communicate with any software that supports MIDI.

Check this API reference to see how gestures are sent via MIDI.

  • Tap

    Note
    by tapping or bouncing

  • Shake

    Note + CC
    by shaking
    or moving

  • Spin

    Note + CC
    by twisting
    or spinning

  • Air

    CC
    when the ball
    is in the air

  • Point

    CC
    like a true knob
    point the logo
    up or down

On Mac

Connecting the Ball as MIDI on Mac is very easy.

Open the Audio MIDI Setup app and from the Window tab menu select Show MIDI Studio. You can also open the MIDI Studio with Cmd + 2 shortcut.

Now click the Bluetooth icon at the top right of the MIDI Studio window.

The Bluetooth MIDI Window will open and you will be able to connect your device.

You can also download the Bluetooth MIDI Connect App, by our friends at Korg, that allows you to quickly access the Bluetooth MIDI Window.

If you have any questions or are having issue with the setup, contact us.

Contact Support

On Windows

On Windows the setup requires two free Apps: MIDIberry and loopMIDI.

First make sure to create a virtual MIDI port with loopMIDI, we will use it to route the Ball's MIDI signal.

Create a new one, give it an appropriate name (e.g. ODD Ball port).

Next, we need to connect to the device using MIDIberry. Once the ball is connected as an input, select the loopMIDI port you created as the output.

Now when you select the loopMIDI port as an input in any software, you will received MIDI message from ODD Ball.
